Pump engineering, without the guesswork

Size the pump. Check the system. Understand the result.

Practical hydraulic calculators and field-ready reference guides for engineers, operators, designers, and technically minded owners.

Explore all calculators Follow the sizing workflow
SYSTEM CHECK DUTY FOUND
Flow524 gpm
Head108 ft
BEP region95 %

Illustrative duty point — use the System Curve calculator for your data.

  • 40+ engineering calculators
  • US + SI unit support
  • Formula visible on every tool
  • Two-source constant checks

Start with a number

Popular pump calculators

Choose a task. Every result includes the method, units, assumptions, and practical guardrails.

View calculator library
01 Hydraulics Total Dynamic Head (TDH) Calculator Calculate total dynamic head from static head, friction loss, vessel pressure, and velocity head — in feet… Open calculator 02 Power & Energy Pump Power Calculator (Hydraulic, Brake & Motor) Calculate hydraulic (water) power, brake power at the shaft, and electrical motor input — in HP and… Open calculator 03 Hydraulics NPSH Available (NPSHa) Calculator Calculate net positive suction head available from altitude or vessel pressure, liquid temperature, static head, and friction… Open calculator 04 Hydraulics Friction Loss Calculator (Darcy-Weisbach) Calculate pipe friction head loss and pressure drop with the Darcy-Weisbach equation — showing velocity, Reynolds number,… Open calculator 05 Hydraulics Friction Loss Calculator (Hazen-Williams) Calculate water friction head loss with the Hazen-Williams equation from flow, pipe size, length, and the C… Open calculator 06 Pump Selection Affinity Laws Calculator (Speed & Impeller Trim) Scale pump flow, head, and power for a change in speed or impeller diameter using the affinity… Open calculator 07 Pump Selection System Curve & Duty Point Finder Find a pump’s real operating point: fit your pump curve, build the system curve H = H_static… Open calculator 08 Power & Energy Motor Sizing Calculator (NEMA & IEC) Size a pump motor from brake power, service factor, and margin — with the next standard NEMA… Open calculator

Gateway calculation

Build total dynamic head before you select a pump.

Combine static elevation, pipe losses, vessel pressure, and velocity head in one defensible system requirement.

  • Clear suction lift sign convention
  • Live US and metric conversion
  • Component-by-component breakdown

Total Dynamic Head

ft
Source position relative to the pump
ft
ft
ft
psi
psi
SG
ft
Total Dynamic Head 227 ft (69.3 m)
  • Static head (h_d − h_s)+130 ft
  • Friction loss (h_fd + h_fs)+28 ft
  • Pressure head (ΔP·K/SG)+69.3 ft
  • Velocity head (Δh_v)+0 ft
Formula & method

TDH = (hd − hs) + (hfd + hfs) + (Pd − Ps)·K / SG + Δhv



K is the pressure-to-head constant: 2.31 ft per psi (US) or 10.2 m per bar (SI), for water at SG = 1.







For preliminary sizing and educational use. Verify final design against manufacturer performance curves and applicable codes; final designs should be reviewed by a licensed professional engineer.
















A defensible workflow


From design flow to a real duty point








  1. 01Set flowDefine the actual process or fixture demand.
    2.

  2. 02Build static headResolve elevations and pressure requirements.
    3.

  3. 03Calculate lossesAdd pipe, valve, and fitting friction.
    4.

  4. 04Check suctionConfirm NPSH margin and velocity limits.
    5.

  5. 05Find duty pointIntersect the pump and system curves.
    6.












Learn the method


Recently updated field guides
